OU6435 Metallographic sample cutting machine

Product overview
OU6435 automatic metallographic cutting machine is controlled by PLC and touch screen, which has very high reliability and powerful control ability. The cutting machine can not only cut the circular workpiece with a diameter of 100mm, but also cut the rectangular sample with a height of 100mm and a width of 300mm. The machine adopts a completely closed structure, and the safety cover of the cutting room is equipped with a large observation window, which is convenient for users to observe the whole cutting process of the sample. Equipped with LED lighting system to achieve effective lighting of the entire cutting room; Equipped with circulating cooling system, it can ensure that the surface of the cut sample is bright, smooth and no burn; Suitable for cutting all kinds of metal, non-metal material samples, in order to observe the material metallographic, lithographic structure. It has the characteristics of automatic cutting process, low noise, easy operation, safety and reliability, etc. It is one of the necessary equipment for laboratory sample preparation.
